| Single Wire Dia: | Copper Wire 0.08 To 0.45 | Wire: | Bare Copper Wire,tinned Wires,silver Jacketed Wire |
|---|---|---|---|
| Also Wire: | Enamelled Wire,double Twist | Max Speed: | 3000rpm |
| Operation Mode: | Touch Screen | Motor Power: | 5.5kw |
| High Light: | double cable machine,double twist buncher | ||
DAHETEC Double Twist Bunching Machine Diameter For Core Wire 500 Take Up Bobbin
Quick Detail:
Equipment models: DHT-500B
Twisting usage: It is applied to the twisting of above 7 pcs of bare copper wires,tinned wires,silver jacketed wires and enamelled wires and double twisting for core wires.
Specification:
1). Single wire diameter: 0.08-0.45mm
2). Stranding section area:0.05-2.5mm2
3). Core wire single wire diameter: 0.5-1.5mm
4). Core wire stranding outer diameter:1.0-3.0mm
5). Pitch : 6.3-52.3(24sections)
6). Take up bobbin size: diameter 500
7). Main motor power:5.5KW
8). Inverter power: 5.5KW
9). Tension control method: touch screen+PLC+magnetic powder clutch,it may ensure the constant
tension from empty bobbin to full bobbin.
10) Protection: Machine will automatically brake when wire inside and outside is broken,the machine will automatically stop when the preset length is arrived.
