Product Details:
|
| Wire: | Silver Jacketed Wire / Electric Wire Manufacturing Machine | Color: | Sky Blue/apple Green |
|---|---|---|---|
| Type: | Gear Type Or Computer Type | Fit For Bobbin: | Diameter 300/250mm |
| Fit For Wire: | 0.08-0.28mm | ||
| High Light: | wire twister machine,metal twisting machine | ||
DAHETEC Tinned Double WireTwist Bunching Machine Gear Type 4.5mm - 17.5mm Pitch
Quick Details:
DAHETEC ® Series for Model A High Speed Bunching Machine and Double Twist Bunching Machine
Japan Technology, product in China
Characteristics:
1. High speed, good stability
2. Wire from the spindle guide wheel directly over the line to the bow belt, avoid scratching, strand jumping for the aluminum plate rotation wheel failure
3. Shaft: use grease lubrication
4. many safety protection, each enabling gate contact is not in place, unable to start or automatic braking
5. Shaft and aluminum plate after high speed dynamic balance treating
6. Noise is lower than the 75 dB
7. Twisted bow: Use Japan high-speed spring steel, after heat treatment.
Specifications:
| Equipment models | DHT-300A | DHT-500A | DHT-630A | DHT-800A |
| Twisting usage | It is applied to the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires,double twisting for core wires. | |||
| Single wire dia(mm) | φ0.08-φ0.28 | φ0.10-0.64 | φ0.15-φ1.04 | φ0.2-φ1.70 |
| Stranding section area (mm²) | 0.035-0.45 | 0.05-2.5 | 0.50-6.0 | 1.0-16 |
| Core wire single wire dia | φ0.25-φ0.8 | φ0.75-φ1.5 | φ0.5-φ2.0 | φ1.0-φ4.0 |
| Core wire stranding outer dia | φ0.5-φ1.6 | φ1.5-φ3.0 | φ1.0-φ4.0 | φ2.0-φ8.0 |
| Pitch(mm) | 4.5-17.5(10zones) | 5.82-53.73(34zones) | 11.48-100(36zones) | 19.8-200(30zones) |
| Direction of lay | Optional for right or left | |||
| Outer dia*bore*outer width | φ300*φ30*160 | φ500*φ70*320 φ400*φ56*300
| φ630*φ56*475 φ630*φ125*475 | φ800*φ80*600
|
| Max rotating speed | 3000(6000twist) | 2200(4400twist) | 1600(3200twist) | 1200(2400twist) |
| Main motor power | 3.7KW | 5.5KW | 7.5KW | 11KW |
| Inverter power | 3.7KW | 5.5KW | 7.5KW | 11KW |
| Tension control method | Mechanism friction | |||
| Magnetic powder clutch | 1.2kgf | 5kgf | 2.5kgf | 10kgf |
| Protection | Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived. | |||
| Brake mode | Electromagnetic brake | |||
| Traversing method | Rolling ring drive units, winding pitch and breadth are adjustable | |||
| Operation mode | Push-button control | |||
| Dimension(mm) | 2300L*1000W*1150H | 2800L*1280W*1300H | 3280L*1600w*1600H | 3600L*1850W*1800H |
