Single Shaft Wire Twister Machine / PLC Control Plastic Extrusion Line

上架时间：2022-03-14

浏览次数：195

产品类型：

产品颜色：

产品价格：￥

Name:	Wire Twister Machine	Take Up Bobbin:	Diameter 630 Mm
Stranding Section Area:	0.35-6mm2	Wire:	Bare Copper Wires, Tinned Wires, Silver Jacketed Wires And Enameled Wires,double Twisting For Core Wires.
Direction Of Lay:	Free To Left Or Right	Pitch:	11.6-100mm(34classes)
Machine Power:	7.5kw	Operation Mode:	Plc Touch Screen Control
High Light:	double twist buncher , double cable machine

Single Shaft Wire Twister Machine / PLC Control Plastic Extrusion Line

Wire Twister Machine Introduction :

New arrival, mainly apply for stranding the electrical wire and automobile wire and other small section area conductor.

Wire Twister Machine Characteristics:

1.Use carbon fiber bow, strong rigidity, uneasy-transformation, small shock, light weight, reduce air friction for high quality of conductors;

2.Use synchronous belt drive, just to replace the guide wheel to change the lay distance, easy to operate.

3.Use spindle to calculate meters, only 0.01% error for a certain wire&cable.

4.Use PLC automatically lubricate spindle bearing, avoid injecting too much or too little grease. Get rid of unnormal noise and worn, cost down for maintenance.

Wire Twister Machine Specifications:

Equipment models	DHT-500B	DHT-650B	DHT-650C	DHT-800B
Twisting usage	Apply for twisting aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm)	0.08-0.45	0.15-1.04	0.12-0.52	0.38-1.70
Stranding section area (mm²)	0.05-2.5	0.35-6.0	0.30-4.0	1.0-16
Core wire single wire dia(mm)	0.5-1.5	0.5-3.0	0.5-2.0	1.0-4.0
Core wire stranding outer dia(mm)	1.0-3.5	1.0-6.0	1.0-4.0	2.0-8.0
Pitch(mm)	6.3-52.3(24classes)	11.6-100(34classes)	11.6-100(34classes)	23-147(20classes)
Direction of lay	Optional for right or left
Outer diaboreouter width	OD500 ID56 H375	OD630 ID56 H475	OD630 ID56 H475 OD630 ID127 H475	OD800 ID80 H600
Max rotating speed	3000rpm(6000twist)	2000rpm(4000twist)	2400rpm(4800twist)	1500rpm(3000twist)
Main motor power	5.5KW	7.5KW	11KW	15KW
Inverter power	5.5KW	7.5KW	11KW	15KW
Tension control method	Touch screen +PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic powder clutch	1.2kgf	5kgf	2.5kgf	10kgf
Protection	automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived
Brake mode	Electromagnetic brake
Traversing method	Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation mode	Touch screen operation
Dimension(mm)	2680L 1250W 1500H		3300L 1550w 1800H	4600L 2000W 2000H

Other Information

FOB SHENZHEN

Payment

TT, L/C

Delivery

FOB SHENZHEN

Origin

China

Minimum Order

1 set

Package

with container
