Product Details:
Payment & Shipping Terms:
|
| Fit For Wire: | 19pcs Copper Wires φ0.16mm - φ0.64mm In One Time | Fit For Bobbin: | Diameter 630 Or 250mm |
|---|---|---|---|
| Wire: | 19pcs Of Copper Wire | Pay Off Bobbin: | Dia180 Or Dia630 |
| Take Up Bobbin: | Dia630 | Can Replace: | Tube Bunching Machine |
| Stranding Section Area: | 0.38-6.0mm2 | Operation Mode: | Touchscreen |
| High Light: | cable twisting machine,wire twist machine | ||
4000Twist Copper Wire Bunching Machine With Touch Screen Operation
Description
It is the latest developed machine. This machine replace the model 200 tube bunching machine with the high productivity(It is 4.5times than tube machine for the 1+6+12 conductors normal bunching)low power, small floor place, low noise and other merits.
Features:
Equipment models | 1+6+12(200bobbin) | DHT-1+6+12(630bobbin) |
Twisting usage | It is applicable to bunching 19pcs copper wires in one time | |
Single wire dia(mm) | φ0.16-φ0.64 | |
Stranding section area (mm²) | 0.38-6.0 | |
Pitch(mm) | 11.6-100(34zones) | |
Direction of lay | Optional for right or left | |
Pay off bobbin size | 8inch,9inch | φ630*φ125*475 |
Max rotating speed | 2000(4000twist) | 2000(4000twist) |
Pay off type | Mechanical friction | Magnetic tension |
Pay off machine power | 5.5KW | 7.5KW |
Take up bobbin size | φ630*φ125*475 | φ630*φ125*475 |
Pay off Inverter power | 7.5KW | 7.5KW |
Main motor power | 7.5KW | 7.5KW |
Take up inverter power | 7.5KW | 7.5KW |
Tension control method | Touch screen+PLC+magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin | |
Magnetic powder clutch | 5.0kgf | 5.0kgf |
Protection | Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived. | |
Brake mode | Electromagnetic brake | |
Traversing method | Rolling ring drive units, winding pitch and breadth are adjustable | |
Operation mode | Touch screen operation | |
Dimension(mm) | 10000L*2500W*1650H | 10000L*2500W*1650H |
