Super developed copper wire twisting machine Bunching Sychronous

上架时间：2022-03-14

浏览次数：218

产品类型：

产品颜色：

产品价格：￥

Fit For Wire:	19pcs Copper Wires φ0.16mm - φ0.64mm In One Time	Fit For Bobbin:	DIA800 Mm
Wire:	19pcs Copper Wire	Tension Control Type:	Magnetic
Type:	Computer Control Metal Twisting Machine	Twisting Usage:	19pcs Copper Wire
High Light:	wire twister machine , automatic wire twisting machine

Super developed copper wire twisting machine Bunching Sychronous

Quick Details:

Series for 1+6+12 bunching machine 19pcs copper wires φ0.16mm - φ0.64mm in one time

a. It is DAHETEC latest developed machine

b. This machine replace the model 200 tube bunching machine with the high productivity(It is

4.5times than tube machine for the 1+6+12 conductors normal bunching)

c. low power, small floor place, low noise and other merits.

Characteristics:

A. New arrival, instead of 200 tube bunching machine, have high productivity(4.5times than normal tube machine for regular 1+6+12 conductors ),

B. Energy-saving, small size, low noise, etc.

Series for 1+6+12 bunching machine
Characteristics:: New arrival, instead of 200 tube bunching machine, have high productivity(4.5times than normal tube machine for regular 1+6+12 conductors ),energy-saving, small size, low noise, etc.
Equipment models	1+6+12(200 and 250bobbin)	1+6+12(630bobbin)
Twisting usage	Apply for bunching 19pcs copper wires synchronous
Single wire dia(mm)	0.16～0.64
Stranding section area (mm²)	0.38～6.0
Pitch(mm)	11.6-100(34classes)
Direction of lay	Free to right or left
Pay-off bobbin size	8inch,9inch	OD630 ID125 H475
Pay-off type	Mechanical friction	Magnetic powder tension
Take-up bobbin size	OD630 ID127 H475 or OD630 ID56 H475 (Customized)	OD630 ID127 H475 or OD630 ID56 H475 (Customized)
Max rotating speed	2000rpm(4000twist)	2000rpm(4000twist)
Pay-off machine power	5.5KW	7.5KW
Pay-off Inverter Power	7.5KW	7.5KW
Take-up motor power	7.5KW	7.5KW
Take-up Inverter Power	7.5KW	7.5KW
Tension control	Touch screen+PLC+magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic powder clutch	5kgf	5kgf
Protection	automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived
Brake mode	Electromagnetic brake
Traversing method	Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation	Touch screen
Dimension(mm)	10000L 2500W 1650H	10000L 2500W 1650H
