Durable Double Wire Twisting Machine With PLC Touch Screen Controller

上架时间：2022-03-14
浏览次数：217
产品类型：
产品颜色：
产品价格：￥
马上咨询
产品详情
Name: Wire Twisting Machine Take Up Bobbin: Diameter 300mm
Fit Wire Diameter: 0.03mm-0.18mm Controller: PLC Touch Screen Controller
Direction Of Lay: Free To Left Or Right Operation Mode: Touch Screen Operation
High Light:

wire twister machine

,

automatic wire twisting machine

Durable Double Wire Twisting Machine With PLC Touch Screen Controller

Wire Twisting Machine Characteristics:



1. With DHT-100 active back-twist pay-off machine to achieve bunching instead of twisting.

2. Especially for twisting small cross-section area.

3. Use synchronous belt drive,

4. Change guide wheel to change lay distance, easy to operate.


Wire Twisting Machine Specifications:



Equipment Models DHT-200B DHT-250B DHT-400B
Twisting Usage Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).
Single Wire Dia(mm) 0.016～0.08 0.03～0.18 0.05～0.32
Stranding Section Area(mm²) 0.0014～0.035 0.0049～0.3 0.0137～1.0
Pitch(mm) 0.8～4.0(14 classes) 0.8~10.8(24classes) 3.1～33.3(24classes)
Direction of Lay Free to right or left

Take-up Bobbin(mm)

Outer dia*bore*outer width

 200*31*135 300*30*185

300*30*185

400*56*300
Max Rotating Speed(rpm) 5000rpm(10000tpm) 4000rpm(8000tpm) 3500rpm(7000tpm)
Main Motor Power 2.2KW 3.7KW 3.7KW
Inverter Power 2.2KW 3.7KW 3.7KW
Tension Control Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin
Magnetic Powder Clutch 0.05kgf 0.3kgf 0.6kgf
Protection

automatically brake/stop 1)wire inside and outside is broken

2)the preset length is arrived
Brake Mode Electromagnetic brake
Traversing Method Rolling wire with ring drive units, winding pitch and breadth are adjustable
Operation Mode Touch Screen Operation
Dimension L*W*H 2000*960*1100 2300*1100*1330 2850*1150*1350


Other Information


FOB SHENZHEN

Payment

TT, L/C

Delivery

FOB SHENZHEN

Origin

China

Minimum Order

1 set

Package

with container

Durable Double Wire Twisting Machine With PLC Touch Screen Controller 0
