Copper Wire Shaftless Active Pay Off Machine Multiple Drawing Bobbins

Merits: It is constant tension,non-twist wire single bobbin pay off machine.Applied to single wire and multiple drawing wires pay off. Match up with the high speed bunching machine,easy to operate,save more floor area.

Series for multiple drawing bobbins active pay off machine:

Model: DHT-630

Usage: Applied to doubling wire pay off, match up with the high speed bunching machine.

Single wire diameter: dia0.08-0.50mm

Pay off bobbin: PND630

Motor power:1.5KW

Tension control: Pneumatic tension

Wire speed: It is feedback the singnal to the inverter to control the rotating speed of motor by displacement sensor.

Control type: Synchronize with the main machine

Protection: Machine is stopped when wire is broken.

Fasten type: Pneumatic fasten
