Product Details:
Payment & Shipping Terms:
|
| Fir Wire: | Copper Wire 0.08-0.45 | Wire: | Bare Copper Wire,tinned Wires,silver Jacketed Wire |
|---|---|---|---|
| Also Wire: | Enamelled Wire,double Twist | Motor Power: | 5.5kw |
| Max Speed: | 3000rpm | Operation Mode: | Touch Screen Operation |
| Magnetic Powder Clutch: | 1.2kgf | Applied Wire: | Above 7 Pcs Of Wire |
| Single Core Wire: | 0.05mm-2.5mm | ||
| High Light: | double twist buncher,steel twisting machine | ||
series for double twist bunching Machine
Chracteristics:
Twisting usage: It is applied to the twisting of above 7 pcs of bare copper wires,tinned wires,silver jacketed wires and enamelled wires and double twisting for core wires.
The technology of this machine is brought from Japan and put in production in China
New arrival, mainly apply for stranding the electrical wire and automobile wire and other small section area conductor.
One: Characteristics:
1.High rotation speed, max up to 2600rpm, is the 1.6 times than normal (1600rpm);
2.Use PLC, hysteresis clutch take-up device imported from German, tension sensor ensure the stable tension and high quality stranding wire, especially for high quality tight line.
3.Use carbon fiber bow, strong rigidity, uneasy-transformation, small shock, light weight, reduce air friction for high quality of conductors;
4.Use synchronous belt drive, just to replace the guide wheel to change the lay distance, easy to operate.
5.Use spindle to calculate meters, only 0.01% error for a certain wire&cable.
6.Use PLC automatically lubricate spindle bearing, avoid injecting too much or too little grease. Get rid of unnormal noise and worn, cost down for maintenance.
Features:
| Equipment models | DHT-500B | DHT-650B | DHT-650C | DHT-800B |
| Twisting usage | It is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires. | |||
| Singlewire dia(mm) | 0.08-0.45 | 0.15-1.04 | 0.12-0.52 | 0.38-1.70 |
| Stranding section area(mm²) | 0.05-2.5 | 0.35-6.0 | 0.30-4.0 | 1.0-16 |
| Core wire single wire dia(mm) | 0.5-1.5 | 0.5-3.0 | 0.5-2.0 | 1.0-4.0 |
| Core wire stranding outer dia(mm) | 1.0-3.5 | 1.0-6.0 | 1.0-4.0 | 2.0-8.0 |
| Pitch(mm) | 6.3-52.3(24classes) | 11.6-100(34classes) | 11.6-100(34classes) | 23-147(20classes) |
| Direction of lay | Optional for right or left | |||
| Outer dia*bore*outer width | OD500 ID56 H375 | OD630 ID56 H475 | OD630 ID56 H475 OD630 ID127 H475 | OD800 ID80 H600
|
| Max rotating speed | 3000rpm(6000twist) | 2000rpm(4000twist) | 2400rpm(4800twist) | 1500rpm(3000twist) |
| Main motor power | 5.5KW | 7.5KW | 11KW | 15KW |
| Inverter power | 5.5KW | 7.5KW | 11KW | 15KW |
| Tension control method | Touch screen +PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin | |||
| Magnetic powder clutch | 1.2kgf | 5kgf | 2.5kgf | 10kgf |
| Protection | Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived. | |||
Delivery date: after receive the down pay ment 45days
Payment terms: 30% down payment, 70% fees of contract before shipment
Packing type: fit for container. water proof simple packing
Minmum no: one set
Price: FOB Shanghai
Contact Person:Mr. Martin
Tel:+86-13827252427
Fax:86-769 8978 6861
