DAHETEC 630 Active Double Shaft Pay Off Machine For Double Twist Bunching Machine

Quick Detail:

630 Series for multiple drawing bobbins active pay-off machine

Characteristics:

1. It is constant tension,non-twist wire single bobbin pay off machine.Applied to single wire and

Multiple drawing wires pay off.Match up with the high speed bunching machine,easy to operate,save

more floor area.

Specification:

Model no : DHT-630

2.1. Usage: Applied to doubing wire pay off,match up with the high speed bunching machine.

2.2. Single wire dia: 0.08mm-0.64mm

2.3. Bobbin size: PND630.

2.4. Motor power:1.5KW

2.5. Tension control: Pneumatic tension

2.6. Wire speed: It is feedback the singnal to the inverter to control the rotating speed of motor

    by displacement sensor.

2.7. Control type: Synchronize with the main machine

2.8. Protection: Machine is stopped when wire is broken.

2.9. Fasten type: Pneumatic fasten.
