0.41 / 0.52 / 0.64mm Copper Wire Bunching Machine With Electromagnetic Brake

上架时间：2022-03-14
浏览次数：208
产品类型：
产品颜色：
产品价格：￥
马上咨询
产品详情
Fit For Wire:19pcs Copper Wires φ0.16mm - φ0.64mm One Time BunchingFit For Bobbin:DIA 630 Or 250mm
Wire:19pcs Copper WireMax Speed:2000(4000twist)
Pay Off Motor Power:5.5kwTake Up Motor Power:7.5kw Cable Braiding Machine
Pay Off Bobbin:DIA 500mmMainly:0.41/0.52/0.64mm
High Light:

cable twisting machine

,

wire twist machine


DAHETEC 0.41 / 0.52 / 0.64mm Copper Wire Bunching Machine With Electromagnetic Brake





Quick Details:



DAHETEC Series for 1+6+12 bunching machine 19pcs copper wires φ0.16mm - φ0.64mm in one time



Characteristics:



1. It is the latest developed machine.

2. This machine replace the model 200 tube bunching machine with the high productivity(It is 4.5times than

tube machine for the 1+6+12 conductors normal bunching)

3. low power, small floor place, low noise and other merits.



Specifications:



Equipment models1+6+12(200bobbin)DHT-1+6+12(630bobbin)  (DAHETEC)
Twisting usageIt is applicable to bunching 19pcs copper wires in one time
Single wire dia(mm)φ0.16-φ0.64
Stranding section area (mm²)0.38-6.0
Pitch(mm)11.6-100(34zones)
Direction of layOptional for right or left
Pay off bobbin size8inch,9inchφ630*φ125*475
Max rotating speed2000(4000twist)2000(4000twist)
Pay off typeMechanical frictionMagnetic tension
Pay off machine power5.5KW7.5KW
Take up bobbin sizeφ630*φ125*475φ630*φ125*475
Pay off Inverter power7.5KW7.5KW
Main motor power7.5KW7.5KW
Take up inverter power7.5KW7.5KW
Tension control method

Touch screen+PLC+magnetic powder clutch,

it may ensure the constant tension from empty bobbin to full bobbin

Magnetic powder clutch5.0kgf5.0kgf
Protection

Machine will automatically brake when wire inside and outside is broken,

the machine will automatically stop when the preset length is arrived.

Brake modeElectromagnetic brake
Traversing methodRolling ring drive units, winding pitch and breadth are adjustable
Operation modeTouch screen operation
Dimension(mm)10000L*2500W*1650H10000L*2500W*1650H





Other Information

FOB SHENZHEN

Payment

TT, L/C

Delivery

FOB SHENZHEN

Origin

China

Minimum Order

1 set

Package

with container
