Product Details:
Payment & Shipping Terms:
|
| Material: | PVC | Direction: | Left To Right |
|---|---|---|---|
| CrossHead: | SOS316 | Pay-off: | 300-630mm Spool |
| Name: | Wire And Cable Extrusion Machine | ||
| High Light: | wire stranding machine,cable stranding machine | ||
Low Noise Wire And Cable Extrusion Machine , Compact Wire Extrusion Equipment
Wire And Cable Extrusion Machine Quick detail :
applied to Ribbion Wire.Merits: 1. Integrated design of annealing and pre-heating, equipped with automatic tension adjusting system, and ensure the wire diameter uniformity of the copper wire elongation and conductor. 2. The plastic extruder main machine using non-adjustable crosshead, which can ensure concentricity of core wire over 95%.
Device structure:drawing machine,annealing machine,extruder,take up machine,tester and other equipments.
Wire And Cable Extrusion Machine Specification:
No. | Name/ Specification
| Qty | Unit | Remark |
12H 500 Pay-off | 1 | Set | For 500 ABS spool | |
Straighten Unit | 1 | Set | DAHETEC | |
Ribbion wire Cross-head | 1 | Pcs | ≤30.0mm | |
￠70 Extruder | 1 | Set | DAHETEC(with PVC screw) | |
1.8MMovable Water Tank | 1 | Set | DAHETEC | |
Dryer Hopper | 1 | Set | DAHETEC | |
Diameter Gauge | Set | SHANGHAI ON-LINE | ||
4M Double Layer Water Tank | 1 | Set | DAHETEC | |
200KG Capsten Device | 1 | Set | For flat wire only | |
159 Meter Counter | 1 | Set | DAHETEC | |
800/630 Double shaft take-up | 1 | Set | DAHETEC | |
Suction Machine(For 70 extruder) | 1 | Set | TAIWAN SHIN | |
Electrics | 1 | Set | Japan's RKC temperature controller;Siemens Motor, Japan's Omron relay and France Schneider Electrics, Germany's Siemens PLC + Taiwan Veiview touch-screen control, +Alarm screen |
Other information:
active pay off or passive pay off
Terms of payment:
FOB Shanghai / Ningbo
Payment terms:
30% down payment,70% before shipment
Delivery time:
45-60 days after receive the downpayment
Origin:
China
Minimum order:
1set
Package:
With container
