Product Details:
|
| Name: | Wire Extruder Machine | Shaft: | One Shaft |
|---|---|---|---|
| Equipped: | Automatic Tension Adjusting System | Outlet Copper Wire Diameter: | Φ0.8～1.78mm |
| Max Speed: | 300 | Advantage: | Low Noise |
| High Light: | wire extrusion machine,wire stranding machine | ||
One Shaft Wire Extruder Machine With Automatic Tension Adjusting System
Wire Extruder Machine Quick detail :
Wire Extruder Machine Specification:
The technology of this machine is brought from Japan and put in production in China
Series for big shaft passive type pay off machine
One whole set pay off machine contains:
A. DHT-1000magnetic passive type pay off machine
B. Centre bundling machine
C. 500kg caterpillar hauling machine
Wire Extruder Machine Specification:
| Equipment usage | BV building wire | LAN cable-2 |
| Inlet copper wire diameter | Φ2.5～3.0mm | Φ2.5-3.0mm |
| Outlet copper wire diameter | Φ0.8～1.78mm | Φ0.4-0.9mm |
| Extrusion finished wire diameter | Φ2.0～5.0mm | Φ0.7-1.5mm |
| max speed | 300 | 1200 |
| max die number | 17 | 17 |
| Mechanical reduction ratio | 20% | 20% |
| Capstan reduction ratio | 15% | 15% |
| drawing power | 45KW | 45KW |
| Annealing type | DC 3phase | DC 3phase |
| Wire accumulator rack | Vertical accumulator | Vertical accumulator |
| Cooling water tank | Double layer | Double layer |
| Capstan | 510Double wheels | 410double wheels |
| Wire accumulator | Horizontal | Horizontal |
| Take up machine | Shaft or coiling machine | Shaft |
Other information:
active pay off or passive pay off
Terms of payment:
FOB Shanghai / Ningbo
Payment terms:
30% down payment,70% before shipment
Delivery time:
45-60 days after receive the downpayment
Contact Person:Mr. Martin
Tel:+86-13827252427
Fax:86-769 8978 6861
