Product Details:
|
| Plastic: | Electric Power Wire/ PU/NYLON Wire | Max Speed: | 500m/min |
|---|---|---|---|
| Color: | Sky Blue | Feed Wire Type: | Active Pay Off Or Tension Pay Off |
| Pay Off Bobbin: | Diameter 500/630/800/1000mm | Material: | Low Smoking Non-halogen Flameresistant |
| Screw Dia: | 70 | ||
| High Light: | plastic extrusion machinery,pvc extruder machine | ||
DAHETEC Nylon Wire Photovoltaic Plastic Extrusion Line / Equipment Flame Resistant
Quick detail:
Low smoking, non-halogen extruder line
Photovoltaic extruder line
Usage:
It is applied to PU,NYLON jacket, low smoking non-halogen flame-resistant environmental building wire.
Specification:
| Model | DHT-70+40 |
| Screw Diameter | Φ70 |
| Screw L/D Ratio | 26:1 |
| Feed wire type | Active pay off or tension pay off |
| Max speed(m/min) | 300 |
| Extrusion output | 150 |
| Power for main machine(KW) | 30 |
| Wire diameter | Φ1.5-12 |
| Max accumulator length(m) | 220 |
| Accumulator | Horizonal accumulator |
| Cooling channel | Folding W type or U type |
| Capstan diameter | Φ510 |
| Capstan power | 7.5HP |
| Take up power | 7.5KW |
| Take up type | Double shaft take-up or shaftless take up |
Other information:
active pay off or passive pay off
Terms of payment:
FOB Shanghai / Ningbo
Payment terms:
30% down payment,70% before shipment
Delivery time:
45days after receive the downpayment
Origin:
China
Minimum order:
1set
Package:
With container
Contact Person:Mr. Martin
Tel:+86-13827252427
Fax:86-769 8978 6861
