Product Details:
|
| Power For Main Machine: | 37kw | Color: | Sky Blue/green |
|---|---|---|---|
| Printer: | Double Head Or Single Head | Pay Off Bobbin: | Diameter 500/630/800/1000mm |
| Screw Ratio: | 25:1 | Material: | FEP,FPA,ETFE Fluorine Plastic |
| Screw Dia: | 80mm | Equipment Type: | 80+45 |
| Accumulator: | Horizonal Accumulator | Extrusion Output: | 200 |
| Wire Diameter: | 5.0-20mm | Extrusion: | High Temperature |
| Fit For Plastic: | PVC PE | Control Type: | Computer Control |
| Take Up: | Shaft Or Coiling Machine | Injection Machine: | Diameter 40mm |
| Capstan Power: | 7.5kw | ||
| High Light: | wire making machine,copper wire machine | ||
φ70+φ35 high speed extrusion machine(Touch screen operation)
Quick detail:
It is mainly for PVC plastic material extrusion for electric wire and cable wire.
Characteristics:
A. Operation direction:right hand machine
B. Main machine centre height 1000mm；
C. Inlet wire:φ0.6-φ3.2mm;
D. Finished wire:φ1.5-φ5.0mm；
E. Production linear speed:350m/min
F. Main machine color:main machine RAL5012 sky blue;electric cabinet: computer white；safe color:yellow.
Machine composition
| No | Name | Numbers | Unit | Note |
| 1. | 630 active pay off | 1 | Pcs | DAHETEC made |
| 2. | 200 swing tension rack | 1 | Pcs | DAHETEC made |
| 3. | Wire straightening | 1 | Pcs | DAHETEC made |
| 4 | Filtrating powder machine | 1 | Pcs | DAHETEC made |
| 5 | U7 head | 1 | pcs | ShangHai Xu Dong |
| 6 | ￠70 main machine | 1 | pcs | DAHETEC Made(contain ZhouShan PVC screw one set) |
| 7 | ￠35movable injection machine | 1 | pcs | DAHETEC made |
| 8 | 1.8 meters movable cooling water tank | 1 | set | DAHETEC made |
| 9 | Diameter measure device | 1 | set | ShangHai On-line |
| 10 | High speed printer | 1 | pcs | DAHETEC made |
| 11 | 8meters single layer cooling water tank | 1 | set | DAHETEC made |
| 12 | 510hauling machine | 1 | pcs | DAHETEC made |
| 13 | 12meters horizontal accumulator rack | 1 | set | DAHETEC made |
| 14 | 159 meter counter | 1 | Pcs | DAHETEC made |
| 15 | Spark tester | 1 | Pcs | Tai Wan He Tai |
| 16 | 1246computer automatic coiling machine | 1 | pcs | |
| 17 | Dry hopper loader | 1 | set | Tai Wan Shin Yi |
| 18 | Suction machine | 1 | set | Tai Wan Shin YI |
| 19 | Electric-control parts | 1 | set |
Other information:
Terms of payment: FOB Shanghai
Payment type:
30% T/T downpayment,70% before shipment
Delivery:
after receive the down payment 45days
Origin:
China
Minimum order:
1set
Package:
With container
