Product Details:
Payment & Shipping Terms:
|
| Plastic: | PVC | Max Speed: | 300m/min |
|---|---|---|---|
| Feed Wire Type: | Active Pay Off Or Tension Pay Off | Pay Off Bobbin: | Dia 500/630/800/1000mm |
| Screw Dia: | 70 | Wire Diameter: | Φ1.5-12 |
| Color: | Sky Blue | Extrusion Output: | 180kg/h |
| High Light: | wire making machine,copper wire machine | ||
DAHETEC Photovoltaic Extrusion Machine with screw dia 70mm for wire dia 1.5-12mm
Quick detail:
A)Photovoltaic extruder line
B)Low smoking, non-halogen extruder line
Specification:
| Model | DHT-70-2 |
| Screw Diameter | Φ70 |
| Screw L/D Ratio | 26:1 |
| Feed wire type | Active pay off or tension pay off |
| Max speed(m/min) | 300 |
| Extrusion output | 180 |
| Power for main machine(KW) | 37 |
| Wire diameter | Φ1.5-12 |
| Accumulator | Horizonal wire accumulator |
| Cooling channel | Folding W type or U type |
| Capstan diameter | Φ510 |
| Capstan power | 7.5HP |
| Take up power | 5.5KW |
| Take up type | 500-800 Double shaft take-up |
Other information:
active pay off or passive pay off
Terms of payment:
FOB Shanghai / Ningbo
Payment terms:
30% down payment,70% before shipment
Delivery time:
45days after receive the downpayment
Origin:
China
Minimum order:
1set
Package:
With container
Contact Person:Mr. Martin
Tel:+86-13827252427
Fax:86-769 8978 6861
