FEP FPA ETFE Plastic Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

FEP FPA ETFE Plastic Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Large Image :  FEP FPA ETFE Plastic Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Product Details:

Place of Origin:China Shenzhen
Brand Name:DAHETEC
Certification:ISO9001:2008
Model Number:DHT-35-1

Payment & Shipping Terms:

Minimum Order Quantity:1set
Price:discussable
Packaging Details:normal packing
Delivery Time:45-60days
Payment Terms:T/T, L/C
Supply Ability:500 SETS/YEAR

FEP FPA ETFE Plastic Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm

Description
Material:FEP, FPA ,ETFE PlasticScrew Dia:35
Feed Wire Type:Active Pay Off  /  Passive Pay OffConductor Dia:0.2-1.02mm
Finished Wire Dia:0.6-1.67Temp Control:Seven Zones
Screw L/D Ratio:25:1

High Light:

wire making machine

,

copper wire machine


FEP FPA ETFE Plastic Extruder Machine For Conductor Dia 0.2-1.02mm Finished 0.6-1.67mm





Quick detail :



It is applicable to FEP(fep,say againF46),FPA(Oxidation of PVC resin silance oxygen radicals)and ETFE(say againF40)etc.fluorine plastic's production.



Specification:



Equipment type35-14565
revolving speed of screw(mm)φ35φ45φ65
Screw L/D ratio25:125:125:1
Extrusion output(kg/h)152045
Power for main machine(kw)111122
conductor dia(mm)Φ0.2~1.02Φ0.6~2.6Φ1.0~5.0
finished wire dia(mm)Φ0.6~1.67Φ1.0~3.2core wireΦ1.5~6.0 sheathed wireΦ6.0~16
pay off typeactive pay off or passive pay off
pre-heater5KVA5KVA5KVA
Evacuating deviceVaccum generator
temp controlseven zonesseven zoneseight zones
diameter measure devicemanual/laser automatic diameter tester device
cooling water tanksingle layer or double layer U type
capstan dia(mm)φ340φ410Φ510
capstan power2.2KWspeed reduction motor
wire accumulator rackhorizontal type
max of accumulator length200M
Take-upBiaxial rooling
take up power2.2KW2.2KW3.7KW
Total power38KW38KW65KW



Other information:



active pay off or passive pay off



Terms of payment:



FOB Shanghai / Ningbo



Payment terms:



30% down payment,70% before shipment



Delivery time:



45-60 days after receive the downpayment



Origin:



China



Minimum order:



1set



Package:



With container
