| Stranding Section Area (mm²): | 6-35 | Core Wire Stranding Outer Dia: | 4 - 10mm |
|---|---|---|---|
| Wire No: | Above 7pcs Of Copper Wire | Fit For Bobbin: | DIA 1000mm |
| Power: | 18.5kw | Brake Mode: | Electromagnetic Brake |
| High Light: | cable manufacturing equipment,single cable machine | ||
CHINA DAHETEC Wire Bunching Machine For Above 7 Pcs Wires 18.5Kw With Touch Screen
Quick Detail:
Model DHT-1000B-4 large wire high speed bunching machine and double twist bunching machine
Japanese Technology, product in China
Apply for the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires ,enameled wires, and double twisting for core wires.
Characteristics:
A) Latest developed machine.
B) This machine replace the traditional model 400 tube bunching machine with the high productivity(it is 4.5times than tube machine for the 1+6 conductors normal bunching),
C) low power, small floor place ,low noise and other merits.
Specification:
Equipment models | DHT-1000B-4 |
Twisting usage | Apply for the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires ,enameled wires, and double twisting for core wires. |
Single wire dia(mm) | φ0.30-φ1.7 |
Stranding section area (mm²) | 6.0-35.0 |
Core wire single wire dia | φ2.0-φ5.0 |
Core wire stranding outer dia | φ4.0-φ10 |
Pitch(mm) | 35-200(12zones) |
Direction of lay | Optional for right or left |
Take up bobbin Outer dia*bore*outer width | φ1000*φ80*750 |
Max rotating speed | 1000(2000twist) |
Main motor power | 18.5KW |
Inverter power | 18.5KW |
Tension control method | Touch screen+ PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin |
Magnetic powder clutch | 20kgf |
Protection | Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived. |
Brake mode | Electromagnetic brake |
Traversing method | Rolling ring drive units, winding pitch and breadth are adjustable |
Operation mode | Touch screen operation |
Dimension(mm) | 4000L*2200W*2100H |
