| Machine Color: | Sky Blue | Take Up Bobbin: | DIAMETER 200 Mm |
|---|---|---|---|
| Max Rotating Speed(rpm): | 5000rpm (10000TPM） | Wire: | Alloy Wires, Tinned Wires, Silver Jacketed Wires And Enamelled Wires |
| Direction Of Lay: | Free To Left Or Right | Stranding Section Area (mm²): | 0.0014 TO 0.035 |
| High Light: | cable processing equipment,single cable machine | ||
China DAHETEC Above 7 pcs Alloy Wire Bunching Machine with Touch Screen Operation
Quick Details:
Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires).
Characteristics:
1.1 High production speed, constant tension from empty to full bobbin, especially for high quality stranding wire.
1.2. Use shaft to calculate meters, less than 0.01% error for a certain wire&cable.
1.3. With DHT-100 active back-twist pay-off machine to achieve bunching instead of twisting.
1.4. Especially for twisting small cross-section area.
1.5. Use synchronous belt drive,
1.6. Change guide wheel to change lay distance, easy to operate.
cable machinery manufacturers |
Specifications:
| Equipment Models | DHT-200B-6 | DHT-250B | DHT-300B | DHT-400B | |
| Twisting Usage | Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires). | ||||
| Single Wire Dia(mm) | 0.016～0.08 | 0.03～0.18 | 0.05～0.28 | 0.05～0.32 | |
| Stranding Section Area(mm²) | 0.0014～0.035 | 0.0049～0.3 | 0.0137～0.45 | 0.0137～1.0 | |
| Pitch(mm) | 0.8～4.0(14 classes) | 0.8~10.8(24classes) | 1.6～21.6(24classes) | 3.1～33.3(24classes) | |
| Direction of Lay | Free to right or left | ||||
Take-up Bobbin(mm) Outer dia*bore*outer width | 200*31*135 | 300*30*185 | 250*30*185 300*30*185 | 300*30*185 400*56*300 | |
| Max Rotating Speed(rpm) | 5000rpm(10000tpm) | 4000rpm(8000tpm) | 3500rpm(7000tpm) | 3500rpm(7000tpm) | |
| Main Motor Power | 2.2KW | 3.7KW | 3.7KW | 3.7KW | |
| Inverter Power | 2.2KW | 3.7KW | 3.7KW | 3.7KW | |
| Tension Control | Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin | ||||
| Magnetic Powder Clutch | 0.05kgf | 0.3kgf | 0.6kgf | 0.6kgf | |
| Protection | automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived | ||||
| Brake Mode | Electromagnetic brake | ||||
| Traversing Method | Rolling wire with ring drive units, winding pitch and breadth are adjustable | ||||
| Operation Mode | Touch Screen Operation | ||||
| Dimension L*W*H | 2000*960*1100 | 2300*1100*1330 | 2300*1100*1330 | 2850*1150*1350 | |
