Product Details:
|
| Annealing Method: | Tube Annealing | Number Of Inlet Wire: | 16pcs |
|---|---|---|---|
| Max Speed: | 300m/min | Pay Off Method: | Brush Pay Off |
| Machine Color: | Sky Blue Or Apple Green | Fit For Wire: | 0.04-0.127mm |
| Pay Off Bobbin: | Diameter 300mm | ||
| High Light: | wire tinning machine,copper wire annealing machine | ||
0.04mm - 0.127mm Wire Annealing Machine Vapour Protection 300M / Min Linear Speed
Quick detail:
Ultra-fine wire high speed tinning machine
The technology of this machine is brought from Japan and put in production in Jiangsu.
Characteristics:
Easy to operate, good annealing heat insulation, save power, adopt nitrogen or steam protection, have individual meter counter for each take up bobbin, stop automatically achieve the preset meter. It may realize ultra-fine annealing tin and achieve industry-leading level.
Specification:
| Equipment models | DHT-TX16 |
| Twisting usage | It is mainly applied to the annealing of ultra-fine round copper wire and alloy wire. |
| Single wire dia(mm) | φ0.04-φ0.127 mm |
| Max numbers of inlet wire | 24pcs |
| Linear speed | Max:300m/min |
| Pay off method | Brush pay off |
| Pay off bobbin model | φ300bobbin |
| Annealing furnace length | 3.0m |
| Annealing method | Tube annealing |
| Annealing protection method | Nitrogen protection or vapour protection |
| Tinned method | Hot dip |
| Capstan control method | Inverter+ motor control or adopt stepless speed regulation motor |
| Equipment total power | 40kw |
| Take up control | Take up is voltage regulator control the moment motor |
| Take up bobbin size | 3inch,5inch,8inch bobbin |
| Traverse control method | Inverter+reducer motor control ball screw traversing,photoelectric induction reversing |
| Installation size | 20000L*1250W*1850H |
