Product Details:
|
| Name: | Wire Annealing Machine | Machine Color: | Sky Blue Or Apple Green |
|---|---|---|---|
| Fit For Wire: | 0.15-0.64mm | Inlet Wire Dia: | 0.08~0.32mm Or 0.15~0.64mm |
| Max Nos Of Inlet Wire: | 24 | Linear Speed: | Max：350m/min |
| Pay Off Method: | Brush Pay Off | Application: | Ultra Fine Round Copper Wire |
| High Light: | wire tinning machine,copper wire annealing machine | ||
Wire Annealing Machine Description:
Wire Annealing Machine Specification:
| Equipment model | DHT-T16 | DHT-T24 | DHT-T48 | DHT-T60 |
| machine usage | applied to the annealing and tinning of ultra-fine round copper wire and alloy wire. | |||
| inlet wire dia | 0.08~0.32mm or 0.15~0.64mm | 0.08~0.32mm | 0.08~0.25mm | |
| max nos of inlet wire | 16 | 24 | 48 | 60 |
| linear speed | max:350m/min | |||
| pay off type | brush pay off | |||
| pay off bobbin type | dia300mm bobbin | |||
| annealing furnace length | five meters or six meters | |||
| annealing type | tube type annealing | |||
| annealing protection type | water seal protection+notrogen or vapor protection | |||
| tinned type | hot dip | No | ||
| capstan control type | inverter+motor control | |||
| equipment total power | 53KW | 61KW | 98KW | 87KW |
| take up control | voltage adjusting controls torque motor take up | |||
| take up bobbin size | five inch,eight inch or five inch,eight inch,10inch | |||
| traverse control type | gear motor+inverter control toothrow traverse | |||
| installation size(mm) | 14500L*1500W*2100H | 18000L*1500W*2100H | 28000L*1800W*2400H | 26000L*1800W*2300H |
Other information:
Terms of payment:
FOB Shanghai
Payment terms:
30% down payment,70% before shipment
Delivery time:
45days after receive the downpayment
Minimum order:
1set
Package:
With container
Contact Person:Mr. Martin
Tel:+86-13827252427
Fax:86-769 8978 6861
