Tinned Copper Wire Twisting Machine 5.5Kw For Medical Equipment / Aerosapce

Main performance parameters of DHT-650C automatic high speed bunching machine

1.Usage: It is applied to the stranding of bare twisted wire, tinned, copper covered aluminum, lacquer wire and alloy wire. 1+6 may twist instead of bunching.

2.Diameter of single core: φ0.12~φ0.45mm

3.Outer diameter of wire: φ0.70~φ2.05mm

4.Crossection area: φ0.30~φ2.5mm2

5.Size of take up spool: φ630mm×430mm×φ125mm(according to client’s drawings to make).

6. Maximum rotating speed: 3000RPM,in normal working speed is 2400RPM,it is not same according to the different wire’s specification.

7.Type of traverse: φ30mm rolling ring traverse, winding pitch and breadth are adjustable.

8. Standard lay length: 34 section 11.6~100mm (enclose list of standard lay length).

9. Main motor: 11KW AC motor +frequency converter

10. Weight of copper load: about 400kg

11.Replace of the capstan wheel to change the lay length.

12. Direction of strand: optional for right or left, only need to pull the reverse rod of the traverse by hands to adjust the lay-length, easy to operate.

13. Brake: electromagnetic brake for external break, automatic stop when wire reach setting meter.

14. Tension control: take up tension is controlled by magnetic powder clutch, PLC follows up and regulates tension, constant tension.

15. Drive bearing: it is adopted imported Japan bearing.

16. Synchronization strap: it is adopted imported American product.

17. Spool from top to bottom: it is adopted manual pump hydraulic landing.

18. Way of spindle lubrication: butter lubrication.

19. Index of noise: about 80dB

20.Dimension: (length×breadth×height): 3500×1450×1650

21. Weight: 4500Kg

Features of machine
