Product Details:
Payment & Shipping Terms:
|
| Color: | Sky Blue/green | Direction Of Lay: | S |
|---|---|---|---|
| Max Speed: | 4000rpm | Fit For Bobbin: | DIA 250mm |
| Applied For Wire: | Copper Wire/silver Jacketed Wire/enamelled Wire | Applied For Bobbin: | Diameter 250mm Bobbin |
| Fit For Wire: | Alloy Wire | ||
| High Light: | wire processing machine,cable manufacturing machine | ||
Alloy Copper wire twister machine , S Lay Sky Blue wire stranding machine
Quick Details:
1. With high rotation speed,with constant tension from empty bobbin to full bobbin, with superior quality
for twist wire
2. it can realize bunching instead of twisting to match up to DHT-100 active back twist pay off machine. And meet requirements of customer to twist wire of small section area,
3. the machine is driven by synchronization strap,only need to change the capstan wheel to change the pitch,easy to operate.
Characteristics:
1. Single wire dia: φ 0.03-φ0.12mm
2. Stranding section area: 0.0049-0.079mm²
3. Pitch: 0.8-5mm
4. Direction of lay: S
5. Take up bobbin: φ250*φ30*200mm
6. Max rotating speed: 4000(8000twist)
7. Inverter power: 3.7kw
8. Tension control method: touch screen+PLC+magnetic powder clutch,it may ensure the constant tension from empty bobbin to full bobbin.
9. Main motor power: 3.7kw
10. Operation mode: touch screen
Specifications:
| Equipment Models | DHT-200B | DHT-250B | DHT-300B | DHT-400B | |
| Twisting Usage | Apply for the bunching of aerospace, medical instrument, cellphone,notebook PC and ultra fine conductor(above seven pcs of alloy wires, tinned wires, silver jacketed wires and enamelled wires). | ||||
| Single Wire Dia(mm) | 0.016～0.08 | 0.03～0.18 | 0.05～0.28 | 0.05～0.32 | |
| Stranding Section Area(mm²) | 0.0014～0.035 | 0.0049～0.3 | 0.0137～0.45 | 0.0137～1.0 | |
| Pitch(mm) | 0.8～4.0(14 classes) | 0.8~10.8(24classes) | 1.6～21.6(24classes) | 3.1～33.3(24classes) | |
| Direction of Lay | Free to right or left | ||||
Take-up Bobbin(mm) Outer dia*bore*outer width | 200*31*135 | 300*30*185 | 250*30*185 300*30*185 | 300*30*185 400*56*300 | |
| Max Rotating Speed(rpm) | 5000rpm(10000tpm) | 4000rpm(8000tpm) | 3500rpm(7000tpm) | 3500rpm(7000tpm) | |
| Main Motor Power | 2.2KW | 3.7KW | 3.7KW | 3.7KW | |
| Inverter Power | 2.2KW | 3.7KW | 3.7KW | 3.7KW | |
| Tension Control | Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin | ||||
| Magnetic Powder Clutch | 0.05kgf | 0.3kgf | 0.6kgf | 0.6kgf | |
| Protection | automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived | ||||
| Brake Mode | Electromagnetic brake | ||||
| Traversing Method | Rolling wire with ring drive units, winding pitch and breadth are adjustable | ||||
| Operation Mode | Touch Screen Operation | ||||
| Dimension L*W*H | 2000*960*1100 | 2300*1100*1330 | 2300*1100*1330 | 2850*1150*1350 | |
